Features

VARIANT Pumping Station for Single/ Two-Family Hauses

Variant Pumpstation Entwässerung Wohnhaus Leitungsführung Einzelanlage Steuerung Außensäule Funktion PE Schacht

Pressure Drainage VARIANT

Variant Pumpstation Druckentwässerung Entwässerung Wohnhaus Anschluss an Druckleitung

Pressure drainage is an ideal wastewater discharge option for single and multi-family homes in rural areas. Through a VARIANT pump station, all the wastewater is pumped unnoticed along the fastest route to the nearest wastewater treatment plant.

Cutting wheel pumps are the first choice for pumping small amounts of wastewater containing fecal matter. The cutting wheels shred all the larger components of the wastewater during operation, allowing the use of smaller pipe cross-sections. The pipeline network thus remains optimally protected against deposits and blockages.

The wastewater only remains in the closed pipeline network for a short time, so that rotting processes and odor emissions cannot occur. Pressure drainage is ideal, especially for longer distances and difficult topographical conditions. Following the course of the terrain, differences in altitude can be overcome without any problems

The investment and operating costs of pressure drainage are often significantly more economical compared to gravity sewer systems.

VARIANT pumping stations are equipped with the non-return ball valves and reliably protect your property against backwater from the public network.

Shaft Systems

LDPE Pumping Station

Variant Pumpstation Auftriebssicherung PE Schacht Grundwasser Montage

Required from a Groundwater Level of 50%

Variant Pumpstation PE Schacht Traversenaufhängung DN 40 Guss Pumpe Einzelanlage

Armatures

Cast Iron Armatures in DN 40 with Traverse Suspension

Single Unit

Variant Pumpstation Armatur Guss Einzelanlage Traversenaufhängung DN 40

Double Unit

Variant Pumpstation Armatur Guss Doppelanlage Traversenaufhängung DN 40

Stainless Steel Armatures in DN 40 with Traverse Suspension

Pressure Drainage VARIANT with PE Tank

Single Unit

Variant Pumpstation Armatur Edelstahl Doppelanlage Traversenaufhängung DN 40

Double Unit

Variant Pumpstation Armatur Edelstahl Einzelanlage Traversenaufhängung DN 40

Pumps

For optimal performance and flow velocity, armatures, pressure lines, and pumps must be precisely tailored to the requirements of your construction project. Our range includes pumps with cutting wheel systems for small volumes of wastewater containing impurities, as well as pumps with free-flow impeller systems. Both variants are available with or without explosion protection. For specific types of wastewater, pumps with special resistance to aggressive substances may be required.

Don’t leave the selection of your pump to chance—let us assist you in choosing the right configuration. To provide you with the best pump for your project, we collaborate with leading wastewater pump manufacturers. Our armature system is compatible with nearly all standard pumps featuring a DIN flange.

Schneidradpumpe Druckentwässerung Variant Pumpe Abwasser KSB Amarex NS 32

Control Unit

Our Control Units Reliably Operate and Monitor Your VARIANT Pump Station. The control system can be installed indoors using wall mounting or outdoors in a weatherproof column. Depending on your application, we offer a well-coordinated solution that integrates control units, level measurement, armatures, pumps, and the shaft.

CEB / CDB Control Unit

Steuerung Pumpstation Variant Garant Dorant Henakt Abwasser Typ CEB CDB

BEN /BDN Control Unit

Steuerung Pumpstation Variant Druckentwaesserung Typ BEN BDN
